Motè Pou Larisi

Pri favorab, livrezon rapid, sèvis alè - ANG se founisè serye ou nan solisyon transmisyon, ki se efikasite segondè, bri ki ba, monte tanperati ki ba, lavi sèvis long, elatriye.

Voye rechèch

Pwodwi Entwodiksyon

Jeneral spesifikasyon nanMotè Pou Larisi:

Pouvwa	0.06 ~ 315kw
Gwosè Frame	56 ~ 355
Faz	Single oswa twa
Klas Efikasite	IE1 ~ IE4
Polonè	2, 4, 6, 8 poto
Pwoteksyon Gwoup	IP44, IP54, IP55, IP56, IP65, IP67
Izolasyon Gwoup	B, F, H
Mounting Kalite	B14, B3, B5, B35, B34
Tanperati anbyen	-15 ~ +40 °C
Altitid	≤1000M

Modèl tipik nan motè pou Larisi

Modèl	Rated pouvwa		Rated pouvwa	Efikasite	Pouvwa	Nan yon	Èske / Nan	Tmax / Tn	Ts / Tn	Pwa, kg
Modèl	KW	HP	RPM	%	faktè	(U=380B)	Èske / Nan	Tmax / Tn	Ts / Tn	Pwa, kg
2P=6,n=1000
АИР 63 А6	0.18	0.25	850	56	0.66	0.74	4.2	2	1.9	6
АИР 63 В6	0.25	0.37	850	59	0.68	0.95	4	2	1.9	6.3
АИР 71 А6	0.37	0.5	885	65.1	0.7	1.23	4.7	2	1.9	12.2
АИР 71 В6	0.55	0.75	885	51	0.72	2.28	4.7	2	1.9	12.5
АИР 80 MА6	0.75	1	910	69	0.72	2.29	5.5	2.1	2	16
АИР 80 MВ6	1.1	1.5	910	72	0.73	3.18	5.5	2.1	2	20
АИР 90 L6	1.5	2	910	77	0.75	3.95	6.5	2.1	2	25
АИР 100 L6	2.2	3	940	80	0.76	5.5	6.5	2.1	2	38
АИР 112 МA6	3	4	955	83	0.77	7.13	6	2.3	2.1	51
АИР 112 МB6	4	5.5	960	83	0.76	9.63	6	2.3	2.1	53
АИР 132 S6	5.5	7.5	960	84	0.76	13.1	6.5	2.1	2.1	80
АИР 132 М6	7.5	10	960	84.5	0.78	17.3	6.5	2	2	91
АИР 160 S6	11	15	965	87.5	0.78	24.5	7	2.1	2	126
АИР 160 M6	15	20	965	89	0.81	31.6	7	2.1	2	148
АИР 180 M6	18.5	25	980	89	0.81	39	7	2.1	2.1	200
АИР 200 M6	22	30	980	90	0.83	44.7	6	2.3	2	240
АИР 200 L6	30	40	980	90	0.82	61.8	7	2.3	2.2	250
АИР 225 M6	37	50	980	91	0.84	73.5	7	2	2.1	330
АИР 250 S6	45	60	985	92.5	0.82	90.1	7	2.1	2	485
АИР 250 M6	55	75	985	92.5	0.82	110	7	2.1	2	530
АИР 280S6	75	100	985	92.5	0.82	150	7	2	2	610
АИР 280M6	90	125	985	93	0.83	177	7	2	2	700
АИР 315S6	110	150	985	94.1	0.86	207	6.7	2	2	1045
АИР 315M6	132	180	985	94.3	0.87	244	6.7	2	2	1100
АИР 355S6	160	220	990	94.6	0.88	292	6.7	2	1.9	1550
АИР 355M6	200	270	990	94.6	0.88	365	6.7	2	1.9	1600
АИР 355L6	250	340	990	94.6	0.88	456	6.7	2	1.9	1700
